How to Install.

installation instruction

installation instruction

Top Covers

1. UNPACK YOUR ORDER

  • Your order will include a number of the following components based on the style and quantity of light pole bases you will be protecting.
  • Foam or Corrugated Disc.
  • Inserts
  • Top Covers
  • Stackable Rings
  • Locking Brackets

2. PREP GROUND AROUND LIGHT POLE BASE

  • If your light pole is anchored into soil, you may have to flatten the surrounding area in order to have your poletectors sit flush to the ground.

3. INSTALL TOP AND LOCKING BRACKETS

  • Once all Poletector rings are in place, put two portions of the top lid in place.
  • Secure with included plastic clips.

4. INSTALL RINGS AND FOAM FROM THE BOTTOM UP

  • Snap together two corresponding rings together while leaving one side open in order to be placed around the light pole base.
  • With the ring in place around the pole, snap together the remaining side so as to make a complete ring.
  • If using foam – squeeze 1 length of foam in between the light pole base and the Poletector ring, thus securing the ring in place.
  • If using corrugated discs – use the open slit to place disc around your light pole, thus securing your Poletector ring in place.
  • Continue by securing the next Poletector ring in place and snapping the bottom edge to the previous Poletector ring’s top edge and then adding foam or disc.

Special Note

Poletector rings can be installed in any order!
